    Polyester Chemical Gutteling Composite Hose Pipe Customized

    Ask Lasest Price
    Brand Name : Hongruntong Marine
    Model Number : HM-CHP90
    Certification : EN13766 & EN13765
    Price : $65-$305
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 2025 Pcs Per Month
    Delivery Time : 5-7 Work Days
    • Product Details
    • Company Profile

    Polyester Chemical Gutteling Composite Hose Pipe Customized

    Willcox Dantec Novaflex Compotec Composite Hose Chemical Gutteling Composite Hose

    Composite Hose Product Introduction
    By Hongruntong Marine


    At Hongruntong Marine, we pride ourselves on delivering reliable and high-performance solutions for the marine and industrial sectors. Our composite hoses are meticulously engineered to meet the demands of modern fluid transfer operations, ensuring safety, durability, and efficiency.


    Product NameComposite Hose Pipe
    Inner Wire & Outer Wire

    Stainless Steel 316

    Stainless Steel 304

    Galvanised Carbon Steel

    Polypropylene Coated Steel

    Aluminium

    Inside Lining

    Polypropylene

    P.T.F.E / E.C.T.F.E

    Poly-amide

    Layers

    Polypropylene Fabrics

    Polypropylene Films

    Poly-amide Fabrics

    Poly-amide Films

    Polyester Fabrics

    Polyester Films

    BOPP Films

    Outer Cover

    PVC Coated Polyester

    Poly-amide

    Polypropylene

    P.T.F.E

    Max. Elongation10% on proof pressure
    Min. Burst Pressure5 x working pressure (Safety factor 5:1)
    Temperature Range-30℃ to +100℃
    Electrical Resistance

    ≤2.5 Ohm/m for under 50mm (2”)

    ≤1.0 Ohm/m for over 50mm (2”)

    OEM, ODMAccept
    StandardEN13766, EN13765

    Polyester Chemical Gutteling Composite Hose Pipe CustomizedPolyester Chemical Gutteling Composite Hose Pipe CustomizedPolyester Chemical Gutteling Composite Hose Pipe CustomizedPolyester Chemical Gutteling Composite Hose Pipe Customized


    Key Features


    Multi-layer Construction
    Crafted with a combination of reinforced materials, our composite hoses offer excellent flexibility while maintaining high strength and resistance to pressure.


    Wide Chemical Compatibility
    Suitable for transferring a variety of fluids, including oil, chemicals, and liquefied gases, thanks to the advanced chemical resistance of its layers.


    Lightweight and Easy to Handle
    Designed to be lighter than traditional rubber or metal hoses, allowing for easier installation, transportation, and handling in tight spaces.


    Temperature and Weather Resistance
    Performs reliably across a broad range of temperatures and withstands harsh environmental conditions, making it ideal for marine and industrial applications.


    Certified Quality
    Manufactured in compliance with international standards, our composite hoses ensure safety and long-term performance.


    Applications

    Marine Fuel Transfer: Safe and efficient transfer of fuels and oils.


    ●​ Chemical Processing: Secure handling of corrosive and non-corrosive chemicals.


    ●​ Petroleum Industry: Reliable for transporting hydrocarbons, lubricants, and other petroleum products.


    ●​ Industrial Use: Versatile solution for demanding industrial fluid transfer operations.


    ModelDimensionsWorking PressureSafety FactorBending RadiusWeightLength
    Composite[mm][inch][bar][psi][kg][m]
    HM-CHP20203/4"162305:1800.840
    HM-CHP25251"162305:1100140
    HM-CHP323211/4"162305:11251.340
    HM-CHP404011/2"162305:11401.540
    HM-CHP50502"162305:11802.540
    HM-CHP656521/2"162305:12003.340
    HM-CHP80803"162305:1260440
    HM-CHP1001004"162305:13806.840
    HM-CHP1251255"162305:14409.240
    HM-CHP1501506"162305:150013.240
    HM-CHP2002008"162305:17501840
    HM-CHP25025010"162305:19002625
    *Note: Various sizes can be customized according to the requirements.

    Polyester Chemical Gutteling Composite Hose Pipe Customized


    FAQ


    What materials are used in the composite hose?

    Answer: Our composite hoses are made with a multi-layer construction of reinforced polypropylene or PTFE, ensuring excellent chemical resistance and durability. The outer cover is coated with abrasion-resistant PVC or rubber for added protection.


    What customization options do you offer?

    Answer: We provide customization for length, diameter, and end fittings (e.g., camlock, flange, or threaded connections). Branding, color coding, and pressure ratings can also be tailored to your needs.


    Do your products meet international standards?

    Answer: Yes, all our composite hoses comply with ISO 9001 and EN 13765 standards. Certificates such as DNV, ABS, or Lloyd’s Register can be provided upon request.


    What support services are included?

    Answer: We offer pre-sale technical consultations, on-time delivery, after-sales support, and repair services. Additionally, we can provide installation guidance and performance testing documentation.
