Hongruntong Marine Composite Hoses: Built for Performance and
Reliability
Aeroflex Apollo Amnitec Composite Hose Manufacturers Assemblies
Blue Compotec
At Hongruntong Marine, we understand that reliability and
efficiency are non-negotiable in demanding industries. That’s why
our composite hoses are engineered with precision and designed to
deliver unmatched performance in fluid transfer operations. Whether
you're managing critical marine bunkering tasks or handling
industrial chemicals, our hoses offer the durability and
flexibility you need to get the job done right.
| Product Name | Composite Hose Pipe |
| Inner Wire & Outer Wire | Stainless Steel 316 Stainless Steel 304 Galvanised Carbon Steel Polypropylene Coated Steel Aluminium |
| Inside Lining | Polypropylene P.T.F.E / E.C.T.F.E Poly-amide |
| Layers | Polypropylene Fabrics Polypropylene Films Poly-amide Fabrics Poly-amide Films Polyester Fabrics Polyester Films BOPP Films |
| Outer Cover | PVC Coated Polyester Poly-amide Polypropylene P.T.F.E |
| Max. Elongation | 10% on proof pressure |
| Min. Burst Pressure | 5 x working pressure (Safety factor 5:1) |
| Temperature Range | -30℃ to +100℃ |
| Electrical Resistance | ≤2.5 Ohm/m for under 50mm (2”) ≤1.0 Ohm/m for over 50mm (2”) |
| OEM, ODM | Accept |
| Standard | EN13766, EN13765 |
What Sets Our Composite Hoses Apart?
Smart Construction for Heavy-Duty Use
Every hose features a multi-layered design of high-grade
polypropylene or PTFE for inner linings, reinforced with galvanized
or stainless steel wire, and covered with abrasion-resistant
materials. The result? A lightweight yet robust solution that
performs under pressure.
Adaptability in Every Environment
From chemical transfer in factories to petroleum handling on
offshore rigs, our hoses excel in diverse conditions. They resist
extreme temperatures, corrosive substances, and environmental wear,
ensuring peak performance wherever they're deployed.
Built to Last
Engineered for longevity, our composite hoses require minimal
maintenance and are thoroughly tested to withstand high pressure
and harsh environments, saving you time and operational costs.
Tailored for Your Needs
Every operation is unique, so we offer fully customizable
options—whether it’s specific lengths, diameters, pressure
capacities, or end fittings like flanges and camlocks. Whatever
your requirements, we’ll tailor a solution that works.
The Benefits of Choosing Hongruntong Marine
Experience You Can Trust
With years of expertise in manufacturing and a commitment to
innovation, we’ve developed a range of products that consistently
exceed customer expectations.
Reliable Support at Every Step
From helping you choose the right hose to providing
post-installation support, our team is here to ensure your
operations run smoothly.
Certified Quality
All our products meet international certifications like ISO 9001
and EN 13765. For specialized needs, we offer optional DNV or ABS
certification.
Applications
Marine fueling and cargo transfer
Industrial chemical handling
Oil and gas operations
Aviation refueling
Food-grade liquid transportation
| Model | Dimensions | Working Pressure | Safety Factor | Bending Radius | Weight | Length |
| Composite | [mm] | [inch] | [bar] | [psi] | [kg] | [m] |
| HM-CHP20 | 20 | 3/4" | 16 | 230 | 5:1 | 80 | 0.8 | 40 |
| HM-CHP25 | 25 | 1" | 16 | 230 | 5:1 | 100 | 1 | 40 |
| HM-CHP32 | 32 | 11/4" | 16 | 230 | 5:1 | 125 | 1.3 | 40 |
| HM-CHP40 | 40 | 11/2" | 16 | 230 | 5:1 | 140 | 1.5 | 40 |
| HM-CHP50 | 50 | 2" | 16 | 230 | 5:1 | 180 | 2.5 | 40 |
| HM-CHP65 | 65 | 21/2" | 16 | 230 | 5:1 | 200 | 3.3 | 40 |
| HM-CHP80 | 80 | 3" | 16 | 230 | 5:1 | 260 | 4 | 40 |
| HM-CHP100 | 100 | 4" | 16 | 230 | 5:1 | 380 | 6.8 | 40 |
| HM-CHP125 | 125 | 5" | 16 | 230 | 5:1 | 440 | 9.2 | 40 |
| HM-CHP150 | 150 | 6" | 16 | 230 | 5:1 | 500 | 13.2 | 40 |
| HM-CHP200 | 200 | 8" | 16 | 230 | 5:1 | 750 | 18 | 40 |
| HM-CHP250 | 250 | 10" | 16 | 230 | 5:1 | 900 | 26 | 25 |
| *Note: Various sizes can be customized according to the
requirements. |
FAQ
1. Do you have stock for sample ?
Yes, you can get available samples in our stock. Free for the
samples, as long as you afford the express freight cost.
2. When can I get the price?
Usually we quote within 24 hours after we get your clear inquiry.
3. How long can I expect to get the sample?
After confirmed files, the samples will be sent to you via express
and arrive in 3-5 days.
4. What about the lead time?
Usually within 25 days.
5. What is your terms of delivery?
We accept FOB, CFR, CIF. You can choose the one which is the most
convenient or cost effective for you.
6. what about payment terms?
L/C at sight ; T/T (30% deposit, balance paid on receipt of B/L
copy.)
