Superior Composite Hoses for Safe and Efficient Fluid Transfer
Cryogenic Chemiflex Continental Composite Hose Pipe Manufacturers
Our composite hoses are designed for high-performance fluid
transfer in a variety of demanding industries. Whether you're
handling hazardous chemicals, petroleum, or industrial gases, these
hoses offer exceptional flexibility, strength, and resistance.
Built with precision and backed by years of manufacturing
expertise, our composite hoses ensure the safe and efficient
transport of fluids under even the most challenging conditions.
| Product Name | Composite Hose Pipe |
| Inner Wire & Outer Wire | Stainless Steel 316 Stainless Steel 304 Galvanised Carbon Steel Polypropylene Coated Steel Aluminium |
| Inside Lining | Polypropylene P.T.F.E / E.C.T.F.E Poly-amide |
| Layers | Polypropylene Fabrics Polypropylene Films Poly-amide Fabrics Poly-amide Films Polyester Fabrics Polyester Films BOPP Films |
| Outer Cover | PVC Coated Polyester Poly-amide Polypropylene P.T.F.E |
| Max. Elongation | 10% on proof pressure |
| Min. Burst Pressure | 5 x working pressure (Safety factor 5:1) |
| Temperature Range | -30℃ to +100℃ |
| Electrical Resistance | ≤2.5 Ohm/m for under 50mm (2”) ≤1.0 Ohm/m for over 50mm (2”) |
| OEM, ODM | Accept |
| Standard | EN13766, EN13765 |
Key Features
Multi-Layer Construction for Maximum Durability
Our composite hoses are built with several layers of high-quality
materials. The inner layers are crafted from chemical-resistant
polymers like PTFE, ensuring that the hose can handle a wide range
of aggressive chemicals without degrading. Reinforced with multiple
layers of steel wire and synthetic fibers, the outer layers provide
added strength, pressure resistance, and protection against
external damage.
Versatile Fluid Compatibility
Our hoses are suitable for transferring a wide variety of fluids,
including oils, chemicals, fuels, and gases. Whether in marine
applications or industrial environments, these hoses offer
excellent compatibility with a broad range of substances, ensuring
safe and reliable fluid handling.
Flexibility and Lightweight Design
One of the standout features of our composite hoses is their
lightweight yet highly flexible design. This flexibility makes them
easy to handle and install, reducing operator fatigue and
minimizing the risk of damage to other equipment during use.
Excellent Pressure and Temperature Resistance
These hoses are designed to operate under high pressure and
temperature extremes, making them ideal for both hot and cold fluid
transfer. Whether you are working with cryogenic gases or
high-temperature fuels, our composite hoses will maintain their
integrity and performance.
Customization Options
We understand that different industries have specific requirements.
That's why we offer customizable options, including hose lengths,
diameters, pressure ratings, and end fittings. From specialized
flanges to custom-threaded connectors, we tailor our products to
meet your exact specifications.
Ideal Applications
► Marine and Offshore Operations
► Chemical and Hazardous Material Handling
► Oil and Gas Industries
► Industrial Fluid Transfer
► Aviation and Refueling Systems
| Model | Dimensions | Working Pressure | Safety Factor | Bending Radius | Weight | Length |
| Composite | [mm] | [inch] | [bar] | [psi] | [kg] | [m] |
| HM-CHP20 | 20 | 3/4" | 16 | 230 | 5:1 | 80 | 0.8 | 40 |
| HM-CHP25 | 25 | 1" | 16 | 230 | 5:1 | 100 | 1 | 40 |
| HM-CHP32 | 32 | 11/4" | 16 | 230 | 5:1 | 125 | 1.3 | 40 |
| HM-CHP40 | 40 | 11/2" | 16 | 230 | 5:1 | 140 | 1.5 | 40 |
| HM-CHP50 | 50 | 2" | 16 | 230 | 5:1 | 180 | 2.5 | 40 |
| HM-CHP65 | 65 | 21/2" | 16 | 230 | 5:1 | 200 | 3.3 | 40 |
| HM-CHP80 | 80 | 3" | 16 | 230 | 5:1 | 260 | 4 | 40 |
| HM-CHP100 | 100 | 4" | 16 | 230 | 5:1 | 380 | 6.8 | 40 |
| HM-CHP125 | 125 | 5" | 16 | 230 | 5:1 | 440 | 9.2 | 40 |
| HM-CHP150 | 150 | 6" | 16 | 230 | 5:1 | 500 | 13.2 | 40 |
| HM-CHP200 | 200 | 8" | 16 | 230 | 5:1 | 750 | 18 | 40 |
| HM-CHP250 | 250 | 10" | 16 | 230 | 5:1 | 900 | 26 | 25 |
| *Note: Various sizes can be customized according to the
requirements. |
FAQ
Q1: Are factory or trading company?
A1: We are the leading manufacturer of composite hose who have many
years experience since 1990.
Q2: What’s your main products?
A2: We mainly produce composite hose, rubber hose, marine hose,
dredging hose and other marine equipment one-stop supply services!!
Q3: Can I get sample?
A3: Yes,We can offer free sample but express charge by your side.
Q4: Do you accept OEM business?
A4: Yes.We do
Q5: What’s the payment term?
A5: T/T,Western Union,Paypal are applicable for us.
Q6: How about the warranty?
A6: 12 months under normally used.
Q7: What’s the delivery time?
A7: Normal model 2-5days,because we have ability to do the
stock.For big order,it takes about 10-15days.
Q8: How to place the order?
A8: You can send us email or inquiry at Alibaba directly.
