8'' Ore Transfer Hose Multi Layer Rubber Structure Enhanced Impact
Vibration Absorption
Introduction
The Flame-Resistant Mining Hose is built for underground mining
operations where fire safety is critical. Made from flame-retardant
rubber compounds and featuring anti-static properties, it helps
reduce fire hazards and electrostatic discharge. Its structure is
engineered to carry water, foam, and other fire suppression agents
with reliability and safety. The rugged outer jacket withstands
abrasion and impact, making it ideal for confined and hazardous
environments.
specifications
| Product Name | Mining Rubber Hose |
| Brand | Hongruntong Marine |
| Tube Material | Hongruntong Grade A++ Natural Rubber |
| Reinforcement | Synthetic Fabric and Wire Helix |
| Cover | Uv, Ozone, and Abrasion-Resistant Synthetic Rubber |
| End Connections | Carbon Steel (Painted, Galvanised, Custom)
Stainless Steel (Ss304, Ss316)
Exotic Alloy |
| Working Pressure | 10-22 Bar |
| Temperature Rating | -40°C to +80°C |
| Safety Factor | 4:1 |
| Application Scenario | Recommended ID (mm) | Wall Thickness (mm) | Working Pressure (Bar) | Temperature Range (°C) |
| Slurry and Tailings Transport | 100–300 | 15–25 | 6–10 | -30 to +80 |
| Mine Dewatering Systems | 50–200 | 10–20 | 4–8 | -10 to +60 |
| Dust Suppression Lines | 25–100 | 5–15 | 4–6 | -10 to +50 |
| Chemical Transfer in Processing | 50–150 | 10–22 | 6–10 | -20 to +90
|
Features
Lightweight Options for Portable Use
Lightweight PVC or composite hoses are ideal for applications
requiring frequent movement or temporary installations.
End Connection Versatility
Compatible with flanges, camlocks, couplings, or quick-connect
fittings, ensuring easy integration into existing systems.
External Wear Protection Options
Hoses can be supplied with an extra outer cover or protective rings
to resist external wear, dragging, or contact with sharp objects.
Low Permeability to Fluids and Gases
Especially in composite hoses, multiple barrier layers ensure
minimal leakage of chemicals, water, or gases during transport.
Application
► Underground Coal Mines
► Tunneling Operations
► Fire Suppression Systems
► Emergency Water Supply
Advantages
UV and Weather Resistance
Outer covers are UV-stabilized and weatherproof, enabling long-term
outdoor use without degradation from sunlight or rain.
Flame Retardant Options Available
Flame-resistant hoses are manufactured with MSHA-approved materials
for enhanced safety in underground coal mines and explosive zones.
Anti Static Properties
Built-in anti-static layers prevent the buildup and discharge of
static electricity, reducing the risk of ignition in flammable
environments.
Reinforced for High Durability
Multiple reinforcement layers (synthetic cord, steel wire, or
fabric) offer excellent strength and burst protection, especially
under high loads.
FAQ
1. Q: Is the hose MSHA approved?
A: Yes, it meets MSHA flame-resistance criteria.
2. Q: Can it be used with foam agents?
A: Yes, it is compatible with fire suppression foam.
3. Q: How flexible is the hose?
A: Designed to be highly flexible for tight routing.
4. Q: What diameters are available?
A: Ranges from 25mm to 200mm.
