    19mm Industrial Hydraulic Hose High Burst Pressure With High Vibration Resistance

    Ask Lasest Price
    Brand Name : Hongruntong Marine
    Model Number : HM-HOH13
    Certification : ABS, DNV, RMRS, CCS, LR, BV, SGS, V-Trust
    Price : USD60-USD610
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1595 Pcs Per Month
    Delivery Time : 5-7 Work Days
    • Product Details
    • Company Profile

    19mm Industrial Hydraulic Hose High Burst Pressure With High Vibration Resistance

    19mm Industrial Hydraulic Hose High Burst Pressure With High Vibration Resistance


    Brief Introduction


    Designed for confined marine engine rooms and compact hydraulic systems, our 2SN ultra-flexible hydraulic hose features a two-layer steel wire braid and low-friction polyurethane inner tube, reducing pressure drop and improving flow efficiency. Its 30% smaller bend radius allows easy installation in tight spaces without kinking.


    specifications


    Place of Origin

    Beijing, China

    Brand

    Hongruntong Marine

    Type

    HMHOH

    Processing Service

    Cutting, Crimping, Assembly

    Material

    Grade A++ Natural Rubber, Imported

    Tube

    Oil Resistant Synthetic Rubber

    Reinforcement

    1-4 Layers Spirals of High Tensile Steel Wire

    Cover

    Abrasion and Weather Resistant Synthetic Rubber

    Temperature Range

    -40 deg C to +120 deg C

    Size

    From 5mm to 51mm or As Request

    Length

    Customized Length

    Logo

    Customized Logo Availabled

    Application

    Industrial


    Model

    I.D

    O.D

    W.P

    B.P

    B.R

    mm

    inch

    min

    max

    mpa

    mpa

    mm

    HMHOH-5

    5

    3/16

    11.1

    13

    25

    50

    100

    HMMOH-6.3

    6.3

    1/4

    12.7

    14

    22.5

    45

    90

    HMMOH-8

    8

    5/16

    14.3

    16

    21.5

    43

    86

    HMMOH-10

    10

    3/8

    16.7

    18

    18

    36

    72

    HMMOH-12.5

    12.5

    1/2

    19.8

    21

    16

    32

    64

    HMMOH-16

    16

    5/8

    22.9

    25

    13

    26

    52

    HMMOH-19

    19

    3/4

    26.9

    29

    10.5

    21

    42

    HMMOH-25

    25

    1

    34.6

    37

    8.8

    17.6

    35.2

    HMMOH-31.5

    31.5

    1-1/4

    42.2

    45

    6.3

    12.6

    25.2

    HMMOH-38

    38

    1-1/2

    49.1

    52

    5

    10

    20

    HMMOH-51

    51

    2

    62.5

    66

    4

    8

    16


    19mm Industrial Hydraulic Hose High Burst Pressure With High Vibration Resistance


    Key Benefits

    ► Exceptional flexibility – Ideal for moving parts, cranes, and articulated machinery.

    High-pressure performance – Rated for 25 MPa dynamic / 40 MPa static pressure.

    Wide fluid compatibility – Works with phosphate esters (Skydrol), HFD, and water-glycol fluids.

    Marine-grade durability – Resists salt spray, humidity, and extreme temps (-54°C to +121°C).


    Why Choose Hongruntong Marine Hydraulic Oil Hoses?


    Structural Design

    Carbon-black-embedded rubber compound with a conductive path (resistance <1MΩ/m per ISO 8031) to prevent static buildup.


    Performance

    35 MPa working pressure, -40°C to +100°C range. Flame-retardant cover (ISO 3795 compliant).


    Fluid Compatibility

    Safe with flammable fluids (e.g., HFA, HFB emulsions).


    Environmental Suitability

    Mandatory for explosive atmospheres (ATEX 2014/34/EU).


    Application


    ► Irrigation Machinery - Mobile hydraulic solutions for water systems


    Oil Rig Hydraulics - H₂S-resistant hoses for drilling operations


    Mining Truck Braking - Extreme-duty hydraulic brake lines


    Wind Turbine Pitch Control - Precision hydraulic adjustment systems


    FAQ


    1. Are hydraulic hoses UV and ozone resistant?

    Yes, most outer covers are resistant to UV, ozone, and weathering, especially for outdoor or marine use.


    2. Can hydraulic hoses be used underground?

    Yes, if they are rated with MSHA flame resistance and proper abrasion protection.


    3. What are hydraulic hose impulse cycles?

    Impulse cycles simulate pressure fluctuations. Quality hoses often exceed 200,000–1,000,000 cycles.


    4. What is a non-skive hydraulic hose?

    A non-skive hose does not require removal of the outer cover before attaching fittings, simplifying assembly.
