Oil Resistant Variants Slurry Suction Hose Low Noise During
Operation And Non Toxic Materials
Description
Optimized for high-volume slurry transfer, these hoses minimize
turbulence with ultra-smooth interiors and wide diameters, boosting
efficiency in mining and dredging operations. The embedded steel
helix prevents suction collapse, while the abrasion-resistant liner
extends lifespan even with coarse materials.
Key benefits include reduced energy consumption, quick
installation, and compatibility with large-scale pumps. Available
in floating or submersible designs, they suit diverse environments,
from river dredging to tailings management. Their durability and
low maintenance needs make them a preferred choice for heavy
industrial use.
Construction |
Inner Liner | Natural rubber in various thicknesses and compounds |
Reinforcement | Nylon cord fabric with spring steel wire helix |
Outer Cover | Black abrasion and UV-resistant natural rubber |
Specifications |
Hose Size | 50~1500 |
Hose Length | Up to 12m |
Pressure Rating | 5-40bar |
Temperature Rating | -40°C to +80°C |
Safety Factor | 4:1 |
Bend Radius | 8 to 10 times diameter (Standard) |
End Fittings | Fixed flanges, swivel flanges, plain cut, cuffed, swollen, custom
fittings |
Flange Types | D, E, F, ANSI 150, ANSI 300, Custom |
Materials | Stainless steel, Hot-dipped galvanised, Carbon steel, Custom paint |
Product Highlights
Chemical Resistant Formulations
Custom compound options available to resist acids, alkalis, oils,
and seawater corrosion for specific industrial applications.
Static-Dissipative Designs
Conductive wire options safely ground static electricity in
explosive environments (ATEX compliant).
Vacuum Rated Performance
Rigorously tested to maintain structural integrity at high vacuum
levels (up to 29" Hg).
Pressure Tested Reliability
Factory hydrostatic tested to 1.5x working pressure (typically
10-25 bar) with certification documentation.
Applications
► Mine dewatering
► Slag handling
► River dredging
► Harbor maintenance
Key Advantages
Marine Grade Options
DNV-GL certified hoses with saltwater-resistant compounds
Smart Hose Technology
Optional embedded wear sensors with IoT connectivity
Burst Safety Margin
All hoses exceed nominal pressure rating by minimum 4:1 safety
factor
Lean Manufacturing
ISO 9001:2015 certified plants with 5S methodology
RFQ
1. Are conductive options available?
Yes, ATEX certified models with integrated copper wire (resistance
<1 ohm/m).
2. Minimum bend radius?
Typically 5x hose diameter (e.g., 100mm for 20" hose) without flow
restriction.
3. Certifications included?
Standard: ISO 9001, CE, MSHA. Optional: DNV, FDA, WRAS, GOST.
4. How are ends finished?
Plain, flanged (ANSI/DIN), or with camlock couplings (Storz, GB,
etc.).
