Excellent Flexibility Wear Resistant Hose Lightweight Design
Reduced Maintenance Needs
Description
Despite their rugged construction, our wear-resistant hoses
maintain outstanding flexibility, allowing easy handling in tight
spaces. The reinforced spiral or braided design prevents kinking,
ensuring uninterrupted flow even under bending or twisting. Perfect
for dynamic applications like industrial vacuum systems or
pneumatic conveying, these hoses combine durability with
maneuverability. The smooth inner bore minimizes material buildup,
enhancing efficiency while maintaining structural integrity under
repetitive movement.
Specifications
| Construction |
| Wear Layer | NR/SBR, highly wear-resistant |
| Reinforcement Layer | High-tensile fabric cord |
| Outer Cover | NR/SBR/EPDM aging/abrasion/
tropical resistant |
| Specifications |
| Inner Diameter/ID(mm) | 50~1500 |
| Length(mm) | 1000~12000 |
| Working Pressure/WP(Bar) | 5~40 |
| Bursting Pressure/BP (Bar) | 15~120 |
| Temperature Rating | -30°C to +75°C |
| Flange Types | AS2129, ASME B16.5, ASME B16.47, AWWA C207, AS4087, BS EN 1092,
BS3293, JIS B2220, SANS 1123, DIN ISO 7005, custom |
| Safety Factor | 4:1 as standard |
| Inner Liner | NR, NBR |
| Reinforcement | Synthetic fabric and wire helix |
| Outer Cover | UV, ozone, and abrasion-resistant rubber |
| End Connections | Carbon steel (painted, galvanised, custom)
Stainless steel (SS304, SS316)
Exotic alloy |
Inner Diameter | Working Pressure | Burst Pressure | Length | Wall Thickness |
| mm | (Mpa) | (Mpa) | (m) | (mm) |
| 300 | 0.4-1.2 | 3.6 | 1-3 | 34-37 |
| 414 | 0.4-1.2 | 3.6 | 1-3 | 35-37 |
| 560 | 0.4-1.2 | 3.6 | 2-3 | 40-45 |
| 600 | 0.4-1.2 | 3.6 | 2-3 | 40-45 |
| 700 | 0.8-1.5 | 4.5 | 2-3 | 40-45 |
| 800 | 1.2-2.5 | 5.5 | 2-3 | 50-52 |
| 900 | 1.5-2.5 | 7.5 | 2-3 | 55-58 |
| 1000 | 2.0-2.5 | 7.5 | 3-5 | 75-78 |
Key Features
Non Toxic Food-Grade Options
FDA/USDA-compliant materials available for food, beverage, and
pharmaceutical industries.
Impact-Resistant Outer Cover
Extra-thick rubber or polyurethane jacket protects against cuts,
tears, and mechanical damage in rugged environments.
Low Maintenance Design
Self-cleaning inner surface and anti-fouling properties reduce
downtime for cleaning and replacements.
Electrically Insulated Variants
Non-conductive rubber layers for safe use near electrical equipment
or high-voltage areas.
Applications
• Cement Plant Material Transfer
• Steel Mill Slag Handling
• Power Plant Fly Ash Removal
• Wastewater Treatment Plants
Why Choose Hongruntong Marine?
Custom Engineering Capabilities
We provide fully customized solutions tailored to specific
application requirements and operating conditions.
Rigorous Quality Control Systems
Comprehensive testing protocols at every production stage guarantee
reliable performance.
Extreme Abrasion Resistance
Our hoses withstand the most demanding abrasive material handling
applications.
Superior Flexibility Characteristics
Engineered to maintain flexibility even in low-temperature
environments.
RFQ
1. Are they suitable for mining?
Absolutely, they handle ore, tailings, and abrasive mining
slurries.
2. How do I maintain a wear resistant hose?
Regular inspections for cuts, abrasions, and proper storage extend
lifespan.
3. Are they more expensive than regular hoses?
Initially yes, but their extended lifespan reduces long-term costs.
4. Can they be repaired if damaged?
Minor damage can sometimes be patched, but severe wear usually
requires replacement.
